Setting Up EOS Node: An Easy Guide to EOS Testnet Setup

Published : Jan 31, 2019

Setting up EOS Node

  • EOS is becoming a popular platform for blockchain application development. Its high scalability enables it to process a large number of transactions quickly. Moreover, these transactions are validated by EOS nodes. These nodes produce blocks containing valid transactions. This blog is a guide to setting up EOS Node in simple steps.

    EOS Blockchain

    EOS is a blockchain (and a coin) used to build 'smart' smart contracts like Ethereum but it's much faster than it.

    Any user who wants to use the EOS platform for creating an account, transferring a token, and issuing a token must have an EOS token to successfully perform the aforementioned actions.

    Furthermore, every user on the EOS blockchain platform holds an amount (in EOS ) for stake network bandwidth, net usage, and RAM.

    So, only an existing user could create a new user as they purchase above- defined asset and gives them to new users (for independent EOS wallet).

    Explore More: EOS Blockchain | A Beginner’s Guide to DApp Development

    Steps To Setting Up EOS Node

    Here's a guide that has steps for setting up the EOS Node jungle2 testnet.

    For setting up EOS Node (Testnet), follow this step

    create and folder
    mkdir /opt/EOSIO
    cd /opt/EOSIO

    git clone https://github.com/eosio/eos --recursive
    cd eos

    git checkout v1.5.2
    git submodule update --init --recursive

    ./eosio_build.sh -s EOS
    ./eosio_install.sh




    This may take a while so don't panic.

    Now, copy the old version.

    mkdir /opt/bin
    mkdir /opt/bin/v1.5.2
    cp /opt/EOSIO/eos/build/programs/nodeos/nodeos /opt/bin/v1.5.2/
    cp /opt/EOSIO/eos/build/programs/cleos/cleos /opt/bin/v1.5.2/
    cp /opt/EOSIO/eos/build/programs/keosd/keosd /opt/bin/v1.5.2/
    ln -sf /opt/bin/v1.5.2 /opt/bin/bin




    Now, update the source version.

    cd /opt/EOSIO/eos
    git checkout -f
    git branch -f
    git pull
    git checkout v1.5.2
    git submodule update --init --recursive


    ./eosio_build.sh -s EOS
    ./eosio_uninstall.sh
    ./eosio_install.sh

    mkdir /opt/bin/v1.5.2
    cp /opt/EOSIO/eos/build/programs/nodeos/nodeos /opt/bin/v1.5.2/
    cp /opt/EOSIO/eos/build/programs/cleos/cleos /opt/bin/v1.5.2/
    cp /opt/EOSIO/eos/build/programs/keosd/keosd /opt/bin/v1.5.2/
    ln -sf /opt/bin/v1.5.2 /opt/bin/bin




    The environment of EOS has been set up successfully.
    Now, we will set up the EOS jungle testnet.

    mkdir /opt/Jungle2Testnet
    cd /opt/Jungle2Testnet
    git clone https://github.com/EOS-Jungle-Testnet/Node-Manual-Installation.git ./




    Suggested Post: Why is EOS blockchain the Best Platform for Commercial-Grade DApps

    Creating an EOS Account

    For setting up the EOS Node, we need an EOS account. We can create an EOS account from here and click Create account.

    The above link needs an account name and public key. You can find a unique account name and private key from this link.

    Now, edit config.ini file that is present in the folder
    /opt/Jungle2Testnet

    And update that file following these details.

    # update here your producer name and that key

    producer-name = oodlestest24
    signature-provider = pub-key=priv-key

    http-server-address = 0.0.0.0:8888 # your node address
    p2p-listen-endpoint = 0.0.0.0:9876
    p2p-server-address = *************:9876 # your public ip

    chain-state-db-size-mb = 16384
    reversible-blocks-db-size-mb = 1024

    contracts-console = true

    p2p-max-nodes-per-host = 100

    wasm-runtime = wabt
    http-validate-host = false
    verbose-http-errors = true
    abi-serializer-max-time-ms = 2000

    access-control-allow-origin = *
    # access-control-allow-headers =
    # access-control-max-age =
    # access-control-allow-credentials = false

    # https-private-key-file =

    allowed-connection = any

    # allowed-connection = specified
    # peer-private-key = ["!!NEW_KEY_PUB!!","!!NEW_KEY_PRIV!!"] #create new key for private peers
    # peer-key = "!![PUBKEY]!!"

    max-clients = 150
    connection-cleanup-period = 30
    network-version-match = 0
    sync-fetch-span = 2000
    enable-stale-production = false

    max-implicit-request = 1500
    pause-on-startup = false
    max-irreversible-block-age = -1
    txn-reference-block-lag = 0

    mongodb-queue-size = 256
    # mongodb-uri =

    plugin = eosio::producer_plugin
    #plugin = eosio::producer_api_plugin
    plugin = eosio::chain_plugin
    plugin = eosio::chain_api_plugin
    plugin = eosio::history_plugin
    plugin = eosio::history_api_plugin

    max-transaction-time=1000

    #EXAMPLE peers please check last one on http://monitor.jungletestnet.io/#p2p
    p2p-peer-address = jungle2.cryptolions.io:9876
    p2p-peer-address = jungle2.cryptolions.io:19876
    p2p-peer-address = jungle-p2p.eosio.cr:2086
    p2p-peer-address = peer.jungle.alohaeos.com:9876
    p2p-peer-address = 145.239.133.201:9876
    p2p-peer-address = 35.165.133.251:8888
    p2p-peer-address = jungle.eosgen.io:9876
    p2p-peer-address = jungle.eosn.io:9876
    p2p-peer-address = 18.223.252.15:9876
    p2p-peer-address = 49.236.137.37:9990
    p2p-peer-address = jungle.eosmetal.io:19876
    p2p-peer-address = jungle2-eos.blckchnd.com:9876

    Now, save the above file. Then, you need to use two port:

    1- 8888 for eos blockchain-communication
    2- 3000 for your eos wallet

    For starting the wallet port, type the following commands:

    cd /opt/Jungle2Testnet
    ./Wallet/start_wallet.sh

    For starting the node, type the following command:

    ./start.sh --delete-all-blocks --genesis-json genesis.json //

    This command will fire only once. If you use this command another time
    then it will delete all downloaded blocks.

    Now, you can check your node information by cleos command or use this link that is running your local system.

    You will get the following response by command ./cleos.sh get info :

    {
    "server_version": "3fddb727",
    "chain_id": "e70aaab8997e1dfce58fbfac80cbbb8fecec7b99cf982a9444273cbc64c41473",
    "head_block_num": 11365262,
    "last_irreversible_block_num": 11364934,
    "last_irreversible_block_id": "00ad6a4636dacefa87c2aa086c9aa361b6c9899b02ed0e4435682f5d7a1c3d69",
    "head_block_id": "00ad6b8e5c191fd7ea0c97106779ba56b4eb176cecc85e712d369b4049b736c3",
    "head_block_time": "2019-01-30T06:03:17.500",
    "head_block_producer": "mosquitometa",
    "virtual_block_cpu_limit": 200000000,
    "virtual_block_net_limit": 1048576000,
    "block_cpu_limit": 192625,
    "block_net_limit": 1048352,
    "server_version_string": "v1.6.0"
    }

    By browser

    http://localhost:8888/v1/chain/get_info

    This will return the node info.

    Now, the setup is complete and it will take time for syncing all blocks that depend on block height.

    Import EOS Account

    Now, you need to import your EOS account that is present in the EOS blockchain. Firstly, you need to create a default wallet.

    cleos Wallet Create

    It will generate a default wallet and give you a password. Store that password securely.

    Now, import your existing wallet into this wallet. Use the following command:
    cleos wallet import ********* (paste here your private key)

    cleos Wallet Keys

    It will show wallet keys.

    For another cleos command, you can check this link

    https://developers.eos.io/keosd/v1.3.0/reference

    For integrating EOS in java you can use this link

    https://github.com/EOSEssentials/eos-java-rpc-wrapper

    Also, Read | EOS Blockchain: Is It a Better Investment for DApp Development

    Set-up of main-net EOS after setting up EOS Node Testnet

    Firstly, set up the environment from the main-net EOS by following this link. Sometimes it is difficult to set up the main net because of its syncing issue. So, there is a shortcut to set up the EOS main net.

    But, there are some limitations in it because here we are going to use the snapshot for the current date. So, it will start syncing from the current data. It means that we haven't held the old data block (it means we don’t have any record of previous-date).

    If you don't need the previous transaction info, use this process to set up the mainnet:

    cd /opt/EOSmainNet
    rm -rf state

    # Download the latest snapshot
    wget $(wget --quiet "https://eosnode.tools/api/snapshots?limit=1" -O- | jq -r '.data[0].s3') -O snapshot.tar.gz

    # Uncompress
    tar xvzf snapshot.tar.gz

    # Start the chain and sync from the provided snapshot
    ./start.sh --snapshot "$(ls -t snapshots/*.bin | head -n1)"

    # Tail the logs to watch the sync in all its glory
    tail -f log.txt




    Furthermore, you can check other date snapshots from this link.

    Conclusion

    You can set up the EOS blockchain node following the above steps. If you are looking for assistance in developing EOS-based applications, then avail our services. Contact our blockchain developers to develop a range of fast, secure, and efficient solutions.
